High Elongation APP Modified Bitumen Waterproofing Membrane/ Bitumen Membrane

Basic Info.

Model NO.	G PY I II
Material	Bitumen
Thickness	3.0mm
Ceiling Tile Type	Polyester Tire
Surface Treatment	Roll Coated
Function	Waterproof
Color	Black
Usage	Outdoor, Indoor
Weight	40kg-55kg/Roll
Coverage	10sqm/ Roll
Transport Package	10 Sqm/Roll Wrapped in Plastic
Specification	3mm or 4mm thick, width 1m, length 10m
Trademark	YOUSUNNY, Yuxiang
Origin	Xinxiang, Henan, China
HS Code	680710000
Production Capacity	300000 Rolls/Year

Packaging & Delivery

Package Size 22.00cm * 22.00cm * 100.00cm Package Gross Weight 40.000kg

Product Description

Product introduction:SBS/APP modified bitumen waterproof membrane is made of bitumen modified with Styrene-Butadiene- Styrene (SBS) or Atactic-polypropylene as dipping and painting. Its upper surface covers PE membrane and color sand or schist, and lower surface is made of PE membrane or sand. Product types include normal SBS/APP, root resistance series, and mineral series.

^{_{Product features:strong impermeability. High tensile strength, high elongation, good dimensional stability, and strong adaptability to base shrinkage deformation and cracking.Good high temperature resistance, SBS is suitable for cold areas, areas with frequent structural deformation and waterproofing of buildings, while APP is suitable for waterproofing of buildings in areas with high temperature and strong solar radiation.Puncture-resistant, break-resistant, tear-resistant, corrosion-resistant, mildew-resistant, and weather-resistant.}}

Application scenarios:Waterproof and moisture-proof for roofs, walls, basements, toilets, etc. in key waterproof projects and industrial and civil buildings; waterproof for bridges, roads, parking lots, swimming pools, tunnels, storage tanks and other buildings; especially suitable for frequent structural deformation Buildings in and cold areas; protection and guarantee of pipelines and anti-corrosion layers, and moisture-proof.PACKAGES
Supply in 10m2 per roll, and packed into plastic bag or non-woven bag.
Technology Data GB18242-2008

NO.	item
				PY	G	PY	G	PYG
1	Content of soluble(g/m²)≥		3.0mm	2100
			4.0mm	2900
			5.0mm	3500
			Test phenomenon		Non flammable		Non flammable
2	Heat resistance		ºC	90		105
			smim	2
			Test phenomenon	No flow drip
3	Low temperature flexibility ºC			-20		-25
				No cracks
4	Water impermeability 30min			0.3Mpa	0.2Mpa	0.3Mpa
5	Tension	Maximum tension (N/50mm)=		500	350	800	500	900
		Second high tension (N/50mm)≥						800
		Test phenomenon		While pulling,bitumen will not crack or separate with the feit
6	Elongation	Maximum elongation %≥		30		40
		Second high elongation%≥						15
7	Oil permeability	pieces≤		2

Instructions for use:Before construction, the qualified base should be cleaned up, and the dust at the edges and corners should be blown away. Brush the base treatment agent to be uniform, do not repeatedly brush. After the grass-roots treatment agent is dried, first of all, according to the design requirements, the additional layer should be laid on the parts of the roof waterproofing project and the underground waterproofing project that need to be added.
Storage and Transportation: 1) Waterproof materials should be stored under dry and ventilated conditions. 2) Different types of membranes must be piled separately. 3) Under usual condition, storage period is one year since production date. 4) Waterproof materials should be put vertically during transportation. 5) It should be kept away from sunshine and rainwater. 6) Transport and storage process should be away from the fire source, storage temperature does not exceed 40ºC, the storage period is 5 year.
